Evolution Gateway (SAE-GW)

4G Core Network Solution
4G Core Products
Achieve superior network efficiency and security with Axyom.Core’s 4G Core solutions. Our suite, including the System Architecture Evolution Gateway (SAEGW), Mobile Management Entity (MME), and Evolved Packet Data Gateway (ePDG), is expertly designed to bridge network components seamlessly, enhance user experiences, and maintain rigorous security standards. Each component is built to support complex network demands while ensuring high availability and optimal performance, allowing you to confidently manage and scale your mobile network operations.
Why do you need 4G Core Solution
Axyom’s 4G core is a scalable, efficient solution for your business that will take your operations to the next level.
Our 4G core solution is vital for fast communication between parties. As the number of users starts increasing, you’ll need a product that can scale according to your growing needs. As you’re using Axyom, you can slowly prepare your business for transition into the 5G network.
While 5G is the future of network infrastructure, 4G is likely to remain a critical part of the network ecosystem for many years to come. The migration from 4G to 5G is a gradual and often costly process, with significant challenges in integrating and managing both technologies concurrently.
Although 5G is considered the more advanced form of cellular communication, there is still merit in using 4G core. Specifically, these networks provide superior results when you’re looking for stable, widespread coverage.
Fast Speed
Many users downplay 4G as it's significantly slower than 5G networks. However, we shouldn’t forget that these networks served businesses for the longest time. 4G is fantastic if you’re looking to make real-time calls, transfer files at a fast speed, browse data, and perform other tasks online.
Excellent Coverage
The biggest advantage of 4G over the newer generation networks is the fact it offers much broader coverage. It offers amazing connections in rural areas, which still rely on old telecommunication towers.
In comparison, 5G companies are still scrambling to install as many cell towers as possible. In many cases, they’re forced to go through a long permit phase that is stalling installation. Furthermore, 5G is almost non-existent in smaller villages and nature, as it doesn’t pay off for providers to install a large number of small 5G cell towers.
Increased Reliability
4G networks use old legacy infrastructure with high coverage. No matter where you are, you can get a clean, reliable signal. As a result, buying a 4G solution is often the best course of action for businesses that don’t care much about download speed, but can’t afford downtimes.
Cost-Effective
Given that infrastructure is already in place and is, by many, considered obsolete, you can get 4G internet relatively cheap. It is also a cheaper solution if you have legacy infrastructure and you don’t want to switch to 5G cloud core.
Axyom.Core 4G Core Benefits
- True Cloud Native: Built from the ground up as a cloud-native solution, Axyom.Core’s 4G Core takes full advantage of cloud infrastructure to deliver flexibility, scalability, and cost efficiency.
- Real Stateless Architecture: Axyom.Core’s 4G Core offers a real stateless design, ensuring efficient resource utilization and high scalability, providing greater flexibility in handling network traffic.
- Converged core: Axyom.Core offers a seamless, forward-looking approach that supports both 4G and 5G networks on a single cloud native platform, allowing providers to capitalize on the best of both technologies and can transition from 4G to 5G NSA/5G SA without any platform upgrade.
- High Performance: The solution is optimized for high performance, enabling service providers to deliver low-latency, high-bandwidth services for diverse use cases.
- Proven Reliability: Trusted by leading communications service providers worldwide.
- Seamless Evolution: Designed for smooth transition to 5G while maximizing LTE performance.
- Scalability: Efficiently supports growing network demands and diverse use cases.
- Advanced Security: Comprehensive measures for secure and reliable network operations.
- 3GPP Compliance: Fully compliant with 3GPP standards.
Here is a breakdown of the main 4G network components:
- LTE user equipment (UE) includes all sorts of smartphones and IoT devices, rely on 4G Radio Access Network to connect to the 4G core. Through RAN, UE can connect further down the line to the external network (e.g. Internet, IMS etc).
- LTE Radio Access Network (RAN) is the wireless component of a 4G mobile network that connects devices to the core network. It utilizes radio frequencies to provide wireless connectivity, enabling devices to communicate with the network and access services like the internet.
- Mobility Management Entity (MME) handles signaling, security, tracking area, roaming, and authentication of user equipment (UE). It also manages the connection between the UE and the core network, ensuring seamless mobility as users move between cells.
- Serving Gateway (SGW) acts as the anchor point for data sessions as users roam between eNodeBs (base stations) and is responsible for routing and forwarding user data packets.
- Packet Data Network Gateway (PGW) provides connectivity to external packet data networks, such as the internet, IMS or other operator networks.
- Home Subscriber Server (HSS) is a central database that stores user-related information, including subscription details, user profiles, and authentication data. It also manages user access authorization and roaming capabilities.
- Policy and Charging Rules Function (PCRF) is a crucial network element within the Evolved Packet Core (EPC). It acts as the central policy decision-making entity.
- OCS (Online Charging System) and OFCS (Offline Charging System) are crucial components for managing and billing user service usage. OCS handles real-time charging for services like voice calls and data sessions, while OFCS records usage data for later billing.
Other important 4G network components are
- Evolved Packet Data Gateway (ePDG) in a 4G network acts as a secure gateway between untrusted non-3GPP networks like WiFi and the core 4G network (EPC).
- Home eNodeB gateway (HeNB-GW) Integrates small cell networks into carrier infrastructure, ensuring efficient data transfer and optimized network communication.
- Security Gateway (SeGW) Provides strong security protocols, protecting data transmission between the networks, with encrypted communication and secure access.
Axyom.Core supported 4G Core components
Axyom’s 4G core relies on various components to make the network work. It supports below 4G Network functions
- Packet Data Network Gateway (PGW)
- Serving Gateway (SGW)
- Mobility Management Entity (MME)
- Evolved packet data gateway (ePDG)
- Home eNodeB Gateway (HeNB-GW)
- Security Gateway (SeGW)
Each of these components ensures high performance and a superb user experience. We also have to mention that our product is fully protected from outside threats, allowing you to focus on your business without having to worry about data integrity.
Evolution Gateway (SAE-GW)
The System Architecture Evolution Gateway (SAE-GW) is designed to simplify and improve mobile networks. The SAE-GW is a combination of the Serving Gateway which is responsible for routing and forwarding of user data packet and the PDN Gateway which is the connecting node between UEs and external networks.
Enhanced Operational Efficiency
Enhances operational efficiency by avoiding the need to process the subscriber context through independent data plane services.
Better Customer Experience
Enhances the end user’s network experience and helps drive demand for new services.
Simplified Network Architecture
Easier transition to an all-IP core network with simplified architecture and open interfaces
- Carrier Grade NAT
- High Availability
- Policy and Charging Control
- Deep Packet Inspection
- Lawful Interception
- Congestion Control
- System Statistics
- Online and Offline Charging
Entity (MME)
The Mobility Management Entity (MME) is the key control node for the access network and provides mobility session management, subscriber authentication, roaming, and handover to other networks.
Reliability and Performance
Proven reliability and performance to meet the most exacting network requirements.
Mobility Management
Provides support for subscriber mobility within the network, as well as support for mobility between networks and keeps track of the current location of subscribers.
Authentication and Security
Supports user access authentication and prevents unwanted access and fraud attempts to the network.
- Network Access Control
- Radio Resource Management
- UE Reachability
- Tracking Area Management
- Roaming Management
- Lawful Interception
- Load Balancing
Data Gateway (ePDG)
Connections paths, particularly from Wi-Fi, are all around us. Securing those paths and integrating them to the cellular network experience is crucial. The Evolved Packet Data Gateway (ePDG) is a virtualized solution providing carrier-grade support of features like Wi-Fi Calling without the risks.
Software Based and Virtualized
Running on standard off the shelf servers, the software based ePDG can be flexibly deployed inside the network on bare metal, as a virtual machine or container.
Support up to 1M secure tunnels per 1U server.
Supporting a Seamless Network Experience
Enhance the customer experience with seamless, secure mobility between VoWiFi and VoLTE as well as applying real-time subscriber, session and application intelligence
Highly Secure
Fully authenticate users, secure data transmissions from the device to the core over untrusted cellular access and act as a termination node of IPSec tunnels established.
Carrier Grade Security
- Authentication: AAA interface for EAP-AKA authentication.
- Encryption: MAC-MD5-96, HMAC-SHA1-96, AES-128-CSC, AES-192-CSC, DES-CBC, 3DEC-CBC, PRF-AES-128-CBC, AES-128, 192 and 256, Null encryption.
Availability
- Uptime: 99.999%
- Upgradability: In-service software upgrade.
- Recovery: Geo redundancy, Auto Failover, Session recovery.
Scaling and Performance
- Scalability: 1M tunnels per 1U server.
- Performance: Security, encryption and authentication applied to every packet with no degradation of performance.
